MangaMino — KiCad Generator — Panelized PCB Dominos

Domino dimensions

Length mm Width mm Corner radius mm Piece gap mm

Front copper pips

Pip diameter mm Pip grid spacing mm

Panelization

Columns Tab width mm Frame margin mm Inner frame clearance Mouse-bite holes Hole Ø mm Spacing mm

Back artwork SVG

Artwork margin mm Mirror for back side SVG rotation

No SVG loaded: the PCB will be generated without back artwork.

Board parameters are locked for production reliability. Upload your SVG artwork, then generate the KiCad file.

The imported SVG should ideally contain path or rect with fill="white". White areas will be generated on B.Cu and B.Mask.

Domino PCB Generator

This software automatically turns a complete domino set into a manufacturing-ready KiCad panel. It generates the .kicad_pcb file with Edge.Cuts routed outlines, an outer frame, tabs, mouse bites, copper pips on the front side and metallic artwork on the back side.

28 double-six dominosJLCPCB panelizationMouse bitesB.Cu + B.MaskCustom back SVG

What the generator does

It computes the position of all 28 pieces, draws rounded outlines, adds breakaway bridges, places mouse-bite holes, and applies the same SVG image to the back of every domino to reveal the copper.

Intended use

The generated file can be opened in KiCad for DRC checking, Gerber export, and fabrication at JLCPCB, PCBWay, or another PCB manufacturer.

Back artwork

Upload one black-and-white SVG. White areas are converted into shapes on B.Cu and B.Mask to create an exposed-metal effect on the back side.

Custom service

I can design a custom PCB domino set for you: manga/cyberpunk artwork, KiCad optimization, panelization, Gerber preparation, and support all the way to the fabrication order.

Premium package available

Exclusive artwork creation, solder mask selection, ENIG gold finish, minimum-width tuning, manufacturing-rule checks, and delivery of a complete upload-ready fabrication package.
